Comet - CAT-300 Comet - CAT-300 Comet - CAT-300

Comet - CAT-300

Product code: 805300
Barcode: 4932273180751

The Comet CAT-300 is a popular antenna tuner for HF frequencies between 1.8 - 60 MHz. With a maximum pass-band power handling of 300 Watts (SSB / PEP). Also for measuring your SWR and output power. The cross needle meter measures Forward Power, Reflected Power and SWR simultaneously. AVG / PEP switch to select average power or SSB / PEP. You can connect two antennas to the Comet CAT-300. With the 'antenna' switch on the front you can select the antenna that you want to use. The cross needle meter is illuminated by 13.8V DC.

Frequency range: 1.8 - 60 MHz
Out of stock - Longer delivery time
€359.95 (297.48 excl. 21% VAT)

Electrical data

  • Backlight display / meter: Yes
  • Power range: 30 / 300 Watts (SSB / PEP)
  • Minimum Power for SWR: 6 Watts
  • Testing function: SWR and Power (FWD and REF / AVG and PEP)
  • Voltage: 13.8 Volt, for display lightning only
  • Power supply for display lightning: Yes
  • Input impedance: 50 Ohm
  • Output impedance: 10 - 600 Ohm
  • Pass-band power rating: Below 300 Watts (SSB / PEP)

Mechanical data

  • Input connector: UHF (PL) female
  • Output connector: 2x UHF (PL) female
  • Length: 200 mm
  • Height: 93 mm
  • Width: 250 mm
  • Weight: 2700 gram

Inside the box

  • Tuner: Yes
  • DC power cable: Yes
  • Installation manual: English
