Comet - CFX-431A

Product code: 805716

Barcode: 4932273007652

Model CFX-431A is the triplexer for transmitting/receiving all 3 bands of HF-150 MHz, 400 MHz band and 900 MHz band at the same time. Using one, or two CFX-431A you can connect transceivers and antennas by one coaxial cable. The combined high quality filters of CFX-431A work to prevent occurrence of TVI on the other hand (isolation of each connectors are over 50 dB). When using CFX-431A for one frequency, the other connectors can be remain as (open), but additional dummy load will be much better.

Frequency range: 1.3-150 / 400-500 / 900-1400 MHz

Shipped next business day

€101.95 (84.26 excl. 21% VAT)

Electrical data

• Power peak: 1.3-60 MHz: 1000W (PEP) / 100-150 MHz: 800W (PEP) / 400-500 MHz: 500W (PEP) / 900-1400 MHz: 200W (PEP)
• VSWR: 1.2 or less
• Impedance: 50 Ohm
• Insertion loss: 1.3-90 MHz: 0.2 dB or less / 400-500 MHz 0.3 dB or less / 900-1400 MHz 0.4 dB or less
• Isolation: more than 50 dB

Mechanical data

• Connector(s) type in: N female
• Connector(s) type out: 1.3-150 MHz: UHF (PL) male / 350-500 MHz: N male / 900-1400 MHz: N male /
• Length: 66 mm
• Height: 26 mm
• Width: 90 mm
• Weight: 325 gram
