Comet - CMZ-7600

Product code: 805250

The Comet CMZ-7600 is a high-tech, mobile dual-band antenna with a foldable element for 144/430 MHz. It offers 2.15/5.3 dBi gain and handles up to 150 Watts of power. It also features wideband reception on 100–170 MHz and 350–470 MHz.

Frequency range: 144 / 430 MHz

Shipped today

€50.95 (42.11 excl. 21% VAT)

Electrical data

• Electrical type: 144 MHz: 1/2 λ / 430 MHz: 5/8 2-step
• Gain: 144 MHz: 2.15 dBi / 430 MHz: 5.3 dBi
• Maximum continuous power: 150 Watts
• Impedance: 50 Ohm
• Polarization: Linear vertical

Mechanical data

• Height: 790 mm
• Weight: 350 gram
• Mounting type: On UHF-female (PL) connector (not included)
• Antenna connector: UHF-male (PL)

Inside the box

• Antenna: Yes
