Comet - CSW-100N

Product code: 805202

Barcode: 4932273181208

The Comet CSW-100N is a 2 way antenna switch with a N female input connector and 2x N female output connectors. Gold-plated inner core connectors.

Frequency range: Up to 1300 MHz

Shipped next business day - Stock: 8

€55.95 (46.24 excl. 21% VAT)

Electrical data

• VSWR: less then 1.2
• Impedance: 50 Ohm
• Isolation: 0-170 MHz over 60 dB / 170-500 MHz over 35 dB / 1250 MHz over 25 dB
• Power range: DC-70 MHz: 1200 Watts (PEP) / 70-170 MHz: 500 Watts (PEP) / 170-1300 MHz: 150 Watts (PEP)

Mechanical data

• Connector(s) type in: N female
• Connector(s) type out: N female
• Length: 78 mm
• Height: 47 mm
• Width: 72mm
• Weight: 430 gram
