CRT - Electro UV V3

CRT - Electro UV V3

Product code: 600825
Factory code: PM 000825
Barcode: 3140650006339

The CRT Electro UV V3 is a compact dual band radio for amateurs equipped with all important functions. Now with VOX function. The Micron V2 offers switchable output power 5 / 10 / 20 Watt in VHF and UHF.

Frequency range: TX/RX: 144-146 MHz / 430-440 MHz
Out of stock - Longer delivery time
€99.95 (82.6 excl. 21% VAT)

Features

  • Display: Yes, Large multi-function color TFT display
  • VOX function: Yes,
  • DTMF: Yes,
  • Modulation: FM (Wide/Narrow)
  • Working mode: UU / UV / VU / VV
  • Tone burst: 1000 Hz / 1450 Hz / 1750 Hz / 2100 Hz
  • Dual watch: Yes
  • Time out Timer: Yes
  • CTCSS / DCS: Yes
  • CTCSS / DCS scan: Yes
  • Scan: Yes
  • External speaker socket: Yes
  • Yes, by computer: Yes, by computer

Electrical data

  • Frequency step: 2.5 kHz / 5 kHz / 6.25 kHz / 10 kHz / 12.5 kHz / 20 kHz / 25 kHz / 30 kHz / 50 kHz /
  • Channels: 500
  • Operating temperature: -20℃ to +60℃

Transmitter

  • Power output (Watts): 20 / 10 / 5 Watt
  • Audio distortion: ≤5%
  • Frequency stability: ±2.5 PPM
  • Type of modulation:
  • Hum & noise:
  • Audio response:

Receiver

  • Frequency stability: ±2.5 PPM
  • Audio response:
  • Adjacent channel selectivity:

Mechanical data

  • Length: 124 mm
  • Height: 36 mm
  • Width: 101 mm
  • Weight: 450 gram
  • Antenna connector: UHF (PL)
  • Mike connector: RJ45 connector

Inside the box

  • Transceiver: Yes
  • Microphone: Yes
  • Mounting bracket: Yes
  • DC power cable: Yes
  • Installation manual: English, French
