CRT - SS 7900 V Turbo CRT - SS 7900 V Turbo CRT - SS 7900 V Turbo

CRT - SS 7900 V Turbo

Product code: 600795
Factory code: TX 000795
Barcode: 3140650006384

Update: now with 5 kHz frequency tuning step.

The CRT SS 7900 V Turbo is a new high power 10m mobile radio with a super large LCD display, offering all the features you could ask for in a mobile 10m radio.

Frequency range: 28.000 - 29.700 MHz
Out of stock - Longer delivery time
€259.94 (214.83 excl. 21% VAT)

Features

  • Modulation: AM / FM / LSB / USB
  • Output power: AM: 30 Watt / FM: 50 Watt / SSB: 60 Watt
  • Channels: 360
  • Display type: LCD display
  • Display colors: Red
  • VOX Function: Yes
  • Noise blanker: Yes
  • Squelch: ASQ (Automatiq Squelch Systeem) / Manual squelch /
  • Keypad lock: Yes
  • Scan function: Yes
  • Memory channels: Yes
  • External speaker socket: Yes
  • External PA socket: Yes
  • S-meter: Yes
  • MIC gain: Yes
  • RF gain: Yes
  • TOT (time out timer): Yes
  • Dual watch: Yes
  • CTCSS codes: Yes 38, decode and encode
  • DCS codes: Yes 104, sub audio code to activate repeater like selective tone
  • HI-CUT: Yes
  • Clarifier: Yes (multifunction) clarifies the voice in SSB (frequency display -500 +500)
  • NRC Filter: Yes, RX/TX noise reduction -adjustable 5 levels- particularly effective in SSB

Electrical data

  • Voltage: 13,8 Volt
  • Frequency step: 1 kHz / 10 kHz / 100 kHz / 100 Hz / 100 MHz /
  • Operating temperature: -20° to +55° C
  • Frequency control: Phase-Locked-Loop Synthesizer
  • Frequency tolerance: ± 5.00 ppm

Transmitter

  • Audio frequency response: AM/FM: 300 Hz - 3.0 kHz / SSB: 450 Hz - 2.5 kHz
  • SSB Carrier Suppression: 55 dB
  • Unwanted sideband: 50 dB
  • Inter modulation distortion SSB: 3rd order, more than -25 dB / 5th order, more than -35dB
  • Impedance: 50 Ohm

Receiver

  • Frequency response: AM/FM: 300 Hz - 3.0 kHz / SSB: 450 Hz - 2.5 kHz
  • Maximum audio power: 3 Watt
  • Internal speaker: 8 Ohm, round
  • SSB sensitivity: 0.25 µV for 10 dB (S+N)/N at greater than 1/2 Watt of audio output.
  • AM sensitivity: 1.0 µV for 10 dB (S+N)/N at greater than 1/2 Watt of audio output.
  • FM sensitivity: 1.0 µV for 20 dB (S+N)/N at greater than 1/2 Watt of audio output.
  • IF frequencies: Double conversion 1st 10.695 MHz / 2nd 455 kHz
  • Image rejection: More than 65 dB
  • Squelch: Adjustable, threshold less than 1.0 μV Automatic Squelch Control (only AM/FM)
  • Adjacent channel selectivity: AM/FM: 60 dB / SSB: 70 dB
  • Automatic Gain Control (AGC): Less than 10 dB change in audio output for inputs from 10 to 100,000 mV
  • RF Gain control: 45 dB adjustable for optimum signal reception

Mechanical data

  • Length: 280 mm
  • Height: 60 mm
  • Width: 200 mm
  • Weight: 1500 gram
  • Antenna connector: UHF (PL) female (SO-239)
  • Mike connector: RJ45 connector

Inside the box

  • Transceiver: 1 pcs
  • Microphone: 1 pcs
  • Fixing screws: 1 set
  • Mounting bracket: 1 pcs
  • Power lead: 1 pcs
  • User Manual: English, French
