Danita - 340

Product code: 11190

Barcode: 5703316111907

New AM/FM multi-band CB radio from Danita with a familiar number. With a VOX function, 7 different display colors, automatic squelch, noise blanker, scan function and other features.

Frequency range: 26.965 - 27.405 MHz

Note - Discontinued

€ -- (Discontinued)

Features

Modulation: AM / FM
Multi-bands: Yes
Output power: 4 Watt
Channels: 40 AM / FM
Display colors: Green / Orange / Purple / Blue / Cyaan / Yellow / White
Export version: Optional: 4 / 8 / 15 Watt
VOX Function: Yes
Noise blanker: Yes
Squelch: ASQ (Automatiq Squelch Systeem) / Manual squelch /
Emergency channel: Yes
Keypad lock: Yes
Scan function: Yes
External speaker socket: Yes
RF gain: Yes
TOT (time out timer): Yes
Dual watch: Yes
Roger Beep: Yes

Electrical data

Voltage: 13,8 Volt
Operating temperature: -20° to +55° C
Operating mode: F3E (FM) / A3E (AM)
Frequency control: PLL synthesizer

Transmitter

Audio frequency response: 300 Hz - 3 kHz
Drain: 3.0 A Max / Receive squelched 0.3 A / Vol max 0.7 A

Receiver

AM sensitivity: 1.0 µV for 10 dB
FM sensitivity: 1.0 µV for 10 dB
Frequency response: 300 Hz - 3.0 kHz
Adjacent channel selectivity: 60 dB
Maximum audio power: 1 Watt
Internal speaker: 8 Ohm, round
IF frequencies: Double conversion 1st 10.695 MHz / 2nd 455 kHz
Audio distortion: Less than 8% @ 1 kHz
Image rejection: 70 dB
Squelch: less than 1 µV

Mechanical data

Length: 124 mm
Height: 101 mm
Width: 36 mm
Weight: 428 gram
Antenna connector: UHF (PL) female (SO-239)
Mike connector: RJ45 connector

Inside the box

Transceiver: 1 pcs
Microphone: 1 pcs
Fixing screws: 1 set
Mounting bracket: 1 pcs
Power lead: 1 pcs
User Manual: English

Downloads

Datasheet: User manual Danita 340
