Himunication - HM130+ (ATIS)

Product code: 48130
Factory code: 48130
Barcode: 6970344033931

Channels conform VDES (VHF Data Exchange System), International standard. Including private channels 31 + 37 for Belgian and Dutch users.

The Himunication HM130+ with ATIS is a mid-range handheld VHF marine radio for mainly leisure use. On the new white backlit display you can clearly read off all information that you need. With a long stand-by time of more than 10 hours.

With features like float and flash, dual- and tri watch and more you can safely enjoy your hobby.

Frequency range: TX: 156.025 - 157.425 MHz / RX: 156.300 - 162.000 MHz
Shipped today
€149.94 (123.92 excl. 21% VAT)

Features

  • Float and flash: Yes
  • Channel 31: Yes
  • 16/9 channel switch: Yes
  • Private channel facility: Yes
  • Dual and tri watch: Yes
  • Display: LCD white backlit
  • Priority channel scan: Yes
  • High/low power selection: Yes
  • ATIS: Yes, one-time programmable by keypad
  • Stand-by time: 10+ hours
  • Key lock: Yes
  • Scan function: Yes
  • Memory channels: Yes
  • Time out timer: Yes, after 3 minutes TX
  • Power save mode: Yes

Electrical data

  • Channels: Conform VDES (VHF Data Exchange System) including private channels 31 + 37
  • Operating temperature (Celsius): -20 to +55 °C
  • Battery lifetime: 10+ hours (TX 5% / RX 5% / stand-by 90%)

Transmitter

  • Power output (Watts): 6 / 3 / 1 Watt
  • Channel spacing: 25 kHz
  • Oscillate Mode: PLL
  • Normal Working Voltage: 7.4V
  • Low Limit Working Voltage: 6.0V
  • Built-ln speaker: 40 mm, 8 Ohm
  • Memory: EEPROM

Mechanical data

  • Length: 130 mm
  • Height: 56 mm
  • Width: 30 mm
  • Weight: 250 gram
  • Antenna connector: SMA

Inside the box

  • Transceiver: Yes
  • Battery: Li-Polymer 1200 mAh
  • Charger: AC 240V / DC 12V desktop charger
  • Wrist strap: Yes
  • Installation manual: English (digital), Dutch (on request by e-mail)
  • Hi-gain flexible rubber antenna: Yes
  • Belt clip: Yes
