K-PO - SDC 5220

Product code: 2169

The K-PO SDC-5220 is a voltage reducer from 18-38V to 13.8V DC power and has an continuous output 18A and a peak of 20A. Connection is via screw terminals (no cable included). The Reducer is suitable for sources such as Land Rovers, commercial vehicles, recreation vehicles, farming equipment and other diesel power vehicles. It is implemented by using Switching Mode Power Supply technology to make it generate less heat and hence higher efficiency. Advanced design, quality production control and sturdy construction assure continue stability and reliability

Shipped today
€71.95 (59.46 excl. 21% VAT)

Electrical data

  • Input power: 18 - 38 Volt
  • Output voltage: 13.8 Volt
  • Continuous output current: 18 A
  • Maximum peak current: 20 A
  • No load current: <80 mA
  • Ripple & noise (p-p): <300 mV
  • Ripple & noise (r.m.s.): <25 mV
  • Load regulation: <100 mV
  • Line regulation: <50 mV
  • Efficiency: >90%
  • Protections: Output over-voltage protection, loss of earth protection, self reset protection, reverse polarity protection, overload protection, short circuit protection
  • Input & output connection type: Push-on flat blade connectors
  • Cooling system: Natural (no fan)
  • Max operating temperature: 50 °C
  • Approvals: CE EN 61000-6-3 ; EN 61000-6-1
  • Indications:: Green LED-OPERATE and Red LED-FAULT
  • e-Mark Approval No.: E4 10R-02 XXXX

Mechanical data

  • Length: 75 mm
  • Height: 32 mm
  • Width: 162 mm
  • Weight: 365 gram
