Maas - RX-40

Product code: 101047
Barcode: 4250158701908

The Maas RX-40 is a compact SWR and Power meter with a frequency range of 140 - 525 MHz. Featuring cross needle design for measuring SWR and output power simultaneously. Compact size makes it very useful for testing mobiles as well as base station installation.

Please note that this meter is equipped with 2x N-female connectors.

Frequency range: 140 - 525 MHz
Shipped today - Stock: 3
€64.95 (53.68 excl. 21% VAT)

Electrical data

  • Backlight display / meter: Yes
  • Impedance: 50 Ohm
  • Power range: 15 / 150 Watts
  • Accuracy: ± 10%
  • Minimum Power for SWR: 1 Watt
  • Testing function: SWR and Power (FWD and REF)
  • Voltage: 13.8 Volt, for display lightning only

Mechanical data

  • Input connector: N female
  • Output connector: N female
  • Length: 95 mm
  • Height: 87 mm
  • Width: 85 mm
  • Weight: 280 gram

Inside the box

  • Meter: Yes
  • DC power cable: Yes
  • Installation manual: English
