President - Jimmy III

Product code: 80085

Factory code: TXPR046

Barcode: 3435991103152

The President range provides access to high-performance transceiver equipment. Utilizing the latest technology, the President Jimmy III 12V marks a new advancement in personal communication, making it the perfect choice for the most demanding CB radio enthusiasts.

Frequency range: 26.965 - 27.405 MHz

Shipped today

€84.95 (70.21 excl. 21% VAT)

Features

• Modulation: AM / FM
• Multi-bands: Yes
• Output power: 4 Watt
• Channels: 40 AM / FM
• Display type: LED display
• Display colors: Orange
• VOX Function: Yes
• Squelch: ASQ (Automatiq Squelch Systeem) / Manual squelch /
• Emergency channel: Yes
• External speaker socket: Yes
• S-meter: Yes

Electrical data

• Voltage: 13,2 Volt

Transmitter

• Audio frequency response: 300 Hz - 3 kHz
• Microphone sensitivity: 3.0 mV
• Frequency allowance: ± 300 Hz
• Transmission interference: inferior to 4 nW (- 54 dBm)
• Emitted power in the adjacent channel: inferior a 20 μW
• Modulated signal distortion: 2 %
• Drain: 13.2 Volt: 2 A

Receiver

• AM sensitivity: 0.5 µV - 113 dBm
• FM sensitivity: 0.35 µV - 116 dBm
• Frequency response: 300 Hz - 3 kHz
• Adjacent channel selectivity: 60 dB
• Maximum audio power: 3 Watt
• Squelch sensitivity: min. 0.2 μV - 120 dBm / max. 1 mV - 47 dBm
• Frequency image rejection rate: 60 dB
• Intermediate image rejection rate: 70 dB
• Drain: 13.2 Volt: 180 - 500 mA

Mechanical data

• Length: 115 mm
• Height: 45 mm
• Width: 130 mm
• Weight: 560 gram
• Antenna connector: UHF (PL) female (SO-239)
• Mike connector: 6 pin connector

Inside the box

• Transceiver: 1 pcs
• Microphone: 1 pcs
• Fixing screws: 1 set
• Mounting bracket: 1 pcs
• Power lead: 1 pcs
• User Manual: English, Spanish, French, Polish

Downloads

• Datasheet: User Manual Jimmy III
