President - Johnson III President - Johnson III President - Johnson III President - Johnson III President - Johnson III President - Johnson III President - Johnson III

President - Johnson III

Product code: 3004344
Factory code: TXPR767
Barcode: 3435991104166

The new President Johnson III is packed with exciting upgrades! It now includes a DIN-mount for smooth installation, a new multi-color display, and an integrated automatic SWR meter. With the addition of the advanced Noise Reduction Circuit (NRC), it's upgraded for the future. Plus, the new USB-C socket ensures you can recharge all your electronics.

Frequency range: 26.965 - 27.405 MHz
Note - Price on request
€ -- (Price on request)

Features

  • Modulation: AM / FM
  • Multi-bands: Yes
  • Output power: 4 Watt
  • Channels: 40 AM / FM
  • Front speaker: Yes
  • Display type: Multi-color backlight
  • Display colors: Green / Orange / Purple / Blue / Cyaan / Yellow / Clear Blue
  • VOX Function: Yes
  • Noise blanker: Yes
  • Squelch: ASQ (Automatiq Squelch Systeem) / Manual squelch /
  • Emergency channel: Yes
  • Scan function: Yes
  • Memory channels: Yes
  • External speaker socket: Yes
  • S-meter: Yes
  • TOT (time out timer): Yes
  • Dual watch: Yes
  • Din mount: Yes
  • External VOX socket: Yes
  • Roger Beep: Yes
  • Automatic SWR meter: Yes
  • SWR (Power Reading /SWR): Yes
  • NRC: Yes
  • USB type C Charging socket: Yes
  • P Channels: Yes
  • Filter ANL: Yes
  • Filter NB: Yes
  • Filter HI-CUT: Yes

Electrical data

  • Voltage: 13,8 Volt / 24 Volt /

Transmitter

  • Audio frequency response: 300 Hz - 3 kHz
  • Microphone sensitivity: 3.0 mV
  • Frequency allowance: ± 300 Hz
  • Transmission interference: inferior to 4 nW (- 54 dBm)
  • Emitted power in the adjacent channel: inferior a 20 μW
  • Modulated signal distortion: <2 %
  • Drain: 13.2 Volt: <2.0 A / 26.4 Volt: <2.0 A

Receiver

  • AM sensitivity: 0,5 µV - 113 dBm
  • FM sensitivity: 0,5 µV - 113 dBm
  • Frequency response: 300 Hz - 3 kHz
  • Adjacent channel selectivity: 60 dB
  • Maximum audio power: 2 Watt
  • Squelch sensitivity: min. 0.2 μV - 120 dBm / max. 1 mV - 47 dBm
  • Frequency image rejection rate: 60 dB
  • Intermediate image rejection rate: 70 dB
  • Drain: min. 400 mA / max. 1000 mA

Mechanical data

  • Length: 120 mm
  • Height: 50 mm
  • Width: 178 mm
  • Weight: 1000 gram
  • Antenna connector: UHF (PL) female (SO-239)
  • Mike connector: 6 pin connector

Inside the box

  • Transceiver: 1 pcs
  • Microphone: 1 pcs
  • Fixing screws: 1 set
  • Mounting bracket: 1 pcs
  • Power lead: 1 pcs
  • User Manual: English, Spanish, French, Polish
  • Din mount: 1 pcs
