President - Ronald President - Ronald President - Ronald President - Ronald President - Ronald President - Ronald President - Ronald

President - Ronald

Product code: 80082
Factory code: TXPR500
Barcode: 3435991327022

The President Ronald is a amateur radio HF mobile transceiver. The Radio is suitable for the 10M amateur band frequency from 28.000 to 29.700 MHz. Also possible for 12M en 11M then you can order the export version.

Frequency range: 28.000 - 29.700 MHz
Shipped today
€179.95 (148.72 excl. 21% VAT)

Features

  • Modulation: AM / FM
  • Multi-bands: Yes
  • Output power: AM: 13 Watt / FM: 35 Watt
  • Display type: LCD display
  • Display colors: Green / Orange / Purple / Blue / Cyaan / Yellow / Clear Blue
  • Export version: 24.715 - 30.105 MHz
  • Noise blanker: Yes
  • Squelch: ASQ (Automatiq Squelch Systeem) / Manual squelch /
  • Emergency channel: Yes
  • Scan function: Yes
  • External speaker socket: Yes
  • External PA socket: Yes
  • S-meter: Yes
  • MIC gain: Yes
  • RF gain: Yes
  • TOT (time out timer): Yes
  • Dual watch: Yes
  • Roger Beep: Yes
  • Filter ANL: Yes

Transmitter

  • Audio frequency response: 300 Hz - 3 kHz
  • Microphone sensitivity: 3.0 mV
  • Frequency allowance: ± 300 Hz
  • Transmission interference: inferior to - 50 dBm
  • Emitted power in the adjacent channel: inferior a 20 μW
  • Modulated signal distortion: 2.0 %
  • Drain: 13.2 Volt: <7.0 A

Receiver

  • AM sensitivity: 0,7 µV - 110 dBm
  • FM sensitivity: 0,35 µV - 116 dBm
  • Frequency response: 300 Hz - 3 kHz
  • Adjacent channel selectivity: 60 dB
  • Maximum audio power: 3 Watt
  • Squelch sensitivity: min. 0.2 μV - 120 dBm / max. 1 mV - 47 dBm
  • Frequency image rejection rate: 60 dB
  • Intermediate image rejection rate: 70 dB
  • Drain: 500 mA max

Mechanical data

  • Length: 175 mm
  • Height: 45 mm
  • Width: 125 mm
  • Weight: 900 gram
  • Antenna connector: UHF (PL) female (SO-239)
  • Mike connector: 6 pin connector

Inside the box

  • Transceiver: 1 pcs
  • Microphone: 1 pcs
  • Fixing screws: 1 set
  • Mounting bracket: 1 pcs
  • Power lead: 1 pcs
  • User Manual: English, Spanish, French, Polish
