Quansheng - UV-K5 Quansheng - UV-K5 Quansheng - UV-K5

Quansheng - UV-K5

Product code: 46005
Factory code: 46005

The Quansheng UV-K5 is a compact dual band handheld transceiver with many interesting features like a cross-band repeater, VOX function, Airband reception, USB-C charging and more. You can use the radio for 144-146 / 430-440 MHz and will be delivered with a 1600 mAh Li-Ion battery pack and table charger.

Frequency range: TX/RX: 144-146 / 430-440 MHz
Shipped today
€32.95 (27.23 excl. 21% VAT)

Features

  • Display: Yes, large LCD display
  • VOX function: Yes
  • DTMF: Yes, and 1750 tone
  • Crossband repeater function: Yes
  • Emergency (SOS) function: Yes
  • Flashlight: Yes
  • High/low power selection: Yes
  • Battery capacity: Li-Ion 1600 mAh (7,2 V)
  • Accessory connector: 2-pin Kenwood connector (K)
  • USB C connector: Yes, can be used for charging
  • Scrambler: Yes, 10 group scrambler
  • AM/FM aviation band reception: Yes
  • NOOA weather reception: Yes
  • Password protection: Yes
  • CTCSS/DCS: Yes
  • Scan: Yes

Electrical data

  • Frequency step: 12.5 kHz / 25 kHz /
  • Channels: 200 Memory channels / 10 Stored FM radio channel quantity / 10 NOAA Channels
  • Wide and narrow bandwidth selection: Yes
  • Operating temperature: -20℃ to +60℃
  • Frequency stability: ±1.0 PPM

Transmitter

  • Power output (Watts): VHF: 5 Watts / UHF: 4 Watts
  • Modulation limit: F3E (12.5 kHz) F3E (25 kHz)
  • Adjacent channel power: 12.5 kHz: 60 dB / 25 kHz: 70 dB
  • Audio distortion: ≤5%
  • Max. frequency deviation: 12.5 kHz: ≤2.5 kHz / 25 kHz: ≤5 kHz
  • Stray power: ≤7.5 uW
  • Residual modulation: 40 dB
  • Emission current: ≤1.5 A

Receiver

  • Sensitivity 50-76 MHz: -121 dBm for 12 dB SINAD (FM)
  • Sensitivity 76-108 MHz: -110 dBm for 20 dB SINAD (WFM)
  • Sensitivity 108-135.9975 MHz: -113 dBm for 10 dB SINAD (AM)
  • Sensitivity 108-135.9975 MHz: -121 dBm for 12 dB SINAD (FM)
  • Sensitivity 136-173.9975 MHz: -123 dBm for 12 dB SINAD (FM)
  • Sensitivity 174-349.9975 MHz: -123 dBm for 12 dB SINAD (FM)
  • Sensitivity 350-399.9975 MHz: -123 dBm for 12 dB SINAD (FM)
  • Sensitivity 400-469.9975 MHz: -123 dBm for 12 dB SINAD (FM)
  • Sensitivity 470-599.9975 MHz: -121 dBm for 12 dB SINAD (FM)
  • Audio frequency: ≥0.5 W
  • Audio distortion: ≤10%

Mechanical data

  • Length: 60 mm
  • Height: 115 mm
  • Width: 37,5 mm
  • Weight: 234 gram
  • Antenna connector: SMA male

Inside the box

  • Transceiver: Yes
  • Battery: Li-Ion 1600 mAh
  • Charger: Desk charger with adapter
  • Antenna: Yes
  • Installation manual: English
  • Belt clip: Yes
  • Hand strap: Yes
