RigExpert - Advanced license MATCH
Product code: 13015
With the ADVANCED license, you can upgrade and add extra features to your RigExpert MATCH, including:
Extended Frequency Range:
- Measurements up to 230 MHz, suitable for both HF and VHF bands.
Advanced Chart Modes:
- Smith Chart: Analyze complex impedance with ease.
Advanced Table Modes:
- Multiband Mode: Visualize and compare antenna performance across multiple bands.
- Multé: Automatically evaluates all HAM bands in your region and assigns a 1–5 star rating for bands where the SWR is below 3.0, ensuring easy performance monitoring.
- Quick Band Access: Provides direct access to selected bands for faster measurements.
Advanced Tools:
- Stub Tuner: For precise tuning of stub antennas.
- Length vs VF: Determine cable length and velocity factor.
- Cable Loss: Accurately measure signal loss in cables.
- Cable Impedance: Measure the characteristic impedance of cables.
- OSL Calibration: Perform Open-Short-Load calibration for higher measurement accuracy.
Additional Features:
- SWR2Air: Broadcasts measured values via the speaker or over the air using the same antenna.
- Bluetooth Connectivity: Enables wireless data management.
Please note that each license is valid for use with only one RigExpert MATCH.
For a detailed comparison between the BASE model, the ADVANCED and RFE licenses, refer to the comparison table available in the 'Downloads' section at the bottom of this product page.
Frequency range: 0.1 - 230 MHz
Shipped today
€109.95
(90.87 excl. 21% VAT)
