Maas - RS-600

Product code: 101193

Barcode: 4250158701922

The Maas RS-600 measures Forward Power, Reflected Power and SWR. Two frequency modes, S1: 1.8 - 160 and S2: 140 - 525 MHz, each with their own set of N-female connectors on the backside. AVG / PEP switch to select average power or SSB / PEP.

It's compact size makes this meter useful for testing both base and mobile installations and for permanent installation in your setup.

Frequency range: 1.8 - 160 / 140 - 525 MHz

Shipped next business day - Stock: 3

€109.95 (90.87 excl. 21% VAT)

Electrical data

• Backlight display / meter: Yes
• Impedance: 50 Ohm
• Power range: 5 / 20 / 200 / 400 Watts
• Accuracy: 5 Watts: ± 5% / 20 Watts: 7.5% / 200 Watts: ± 10% / 400 Watts: ± 12.5%
• Minimum Power for SWR: 0.5 Watt
• Insertion loss: 0.2 dB
• Testing function: SWR and Power (FWD and REF / AVG and PEP)
• Voltage: 13.8 Volt, for display lightning only
• 200 / 400 Watts power switch: Yes, on backside
• Maximum power handling: 400 Watts 25 sec on, 35 sec off

Mechanical data

• Input connector: 2x N female
• Output connector: 2x N female
• Length: 150 mm
• Height: 65 mm
• Width: 100 mm
• Weight: 720 gram

Inside the box

• Meter: Yes
• DC power cable: Yes
• Installation manual: English
