Sirio - CX 868 N-f

Product code: 210750100

Factory code: 2107501.00

UHF antennas for base station service made of high quality materials to get the best performance and the maximun efficiency. They are completely manufactured with aluminium tubes and thermoplastic UV stabilized for its great robustness and supplied with a solid steel bracket for an easy and safe installation. They are DC-grounded for a perfect protection against the discharges and no tuning is required. Simple and strong, they are particularly recommended for a professional use.

Frequency range: 845 - 885 MHz

Shipped next business day

€49.95 (41.28 excl. 21% VAT)

Electrical data

• Electrical type: 3/4 l Coax J-pole
• Gain: 0 dBd; 2.15 dBi
• VSWR: ≤ 1.5
• Maximum continuous power: 100 Watts (CW)
• Impedance: 50 Ohm
• Polarization: Linear vertical

Mechanical data

• Materials: Aluminium, chromed brass, stainless steel 17/7 PH
• Mast Ø: 35 - 54 mm
• Max wind resistance: 180 km/h
• Height: 350 mm
• Weight: 470 gram
• Mounting type: On mast
• Antenna connector: N-female, gold plated central pin

Inside the box

• Antenna: Yes
• Mounting parts: Yes
• Installation manual: English

Downloads

• Datasheet: Id 184 15 05 2018 cx840 868 900
