Sirio - GP 6-E

Product code: 2108101
Factory code: 2108101.00
Barcode: 8056182112804

2x5/8 λ Ground Plane base station collineair antenna for land and marine service. It works on the frequency range of 140 - 175 MHz by using the cutting diagram enclosed. The matching coil is DC feeded for a perfect protection from the static discharges. GP 6-E is made of non-corrosive aluminium and assembled on a very strong base of die-cast metal to get the maximum robustness and the best performance. Tuning is easy by following the attached directions.

Frequency range: 140 - 175 MHz tunable
Out of stock - Longer delivery time
€63.95 (52.85 excl. 21% VAT)

Electrical data

  • Electrical type: 2×5/8 λ ground plane colinear
  • Gain: 3.8 dBd, 5.95 dBi
  • VSWR: ≤ 1.2
  • Bandwidth: 5.2 MHz ≤ 2.0
  • Power peak: 200 Watts (CW)
  • Impedance: 50 Ohm
  • Polarization: Linear vertical
  • Feed system: Transformer DC-Ground / Base

Mechanical data

  • Materials: Aluminium, brass, nylon
  • Mast Ø: 25 - 30 mm
  • Max wind resistance: 120 km/h
  • Height: 3060 mm
  • Weight: 750 gram
  • Mounting type: On mast
  • Antenna connector: UHF-female

Inside the box

  • Antenna: Yes
  • Mounting parts: Yes
  • Installation manual: English
