Sirio - GP 901 C N-f

Product code: 851

Factory code: 2107606.00

UHF colinear Ground Plane antenna suitable for the base station service covering the frequency range of 870 - 960 MHz. The main whip and the radials are made of 17/7 PH stainless steel and its base is of chromed brass to get the best robustness. Easy to fit, it is suitable for a handy installation everywhere. No tuning required.

Frequency range: 870 - 960 MHz

Shipped today

€49.95 (41.28 excl. 21% VAT)

Electrical data

• Electrical type: 1/4 λ + 2x 1/2 λ colinear
• Gain: 6 dBd, 8.15 dBi
• VSWR: See the product manual under downloads
• Maximum continuous power: 50 Watts (CW)
• Impedance: 50 Ohm
• Polarization: Linear vertical

Mechanical data

• Materials: Aluminium, chromed brass, stainless steel 17/7 PH
• Mast Ø: 35 - 54 mm
• Max wind resistance: 180 km/h
• Height: 800 mm
• Weight: 670 gram
• Mounting type: On mast
• Antenna connector: N-female
• Radial length: 75 mm

Inside the box

• Antenna: Yes
• Mounting parts: Yes
• Installation manual: English

Downloads

• Datasheet: Id 151 13 07 2020 GP 900 C GP 901 C
