Sirio - HGO 4G LTE Cable

Product code: 21540045

Factory code: 2154004/5CO

Barcode: 8056182115614

New - LTE improved for the LTE low band covering the 790 - 960 MHz and 1710 - 2700 MHz bands for GSM 900/1800 dual-band, UMTS, WLAN and LTE systems. Thanks to its very new electrical structure, the antenna guarantees high gain on all bands, no tuning required. It is protected by thermoplastic UV stabilized material for the best robustness and long life for outdoor and indoor installations. It is supplied with plastic bracket and fixing hardware for an easy installation on the mast or on the wall and it comes with 5 meter low loss cable with SMA-male connector.

Frequency range: 790 - 960 MHz / 1.71 - 2.7 GHz

Out of stock - Longer delivery time

€79.94 (66.07 excl. 21% VAT)

Electrical data

• Electrical type: Multi band dipole array
• Gain: GSM 900/1800: 5 dBi / UMTS: 6 dBi / WLAN/LTE: 5-6 dBi
• VSWR: See the product manual under downloads
• Maximum continuous power: GSM 900/1800: 20 Watts (CW) / UMTS: 10 Watts (CW) / WLAN/LTE: 6 Watts (CW)
• Impedance: 50 Ohm
• Polarization: Linear vertical
• Cable: Yes
• Cable length: 5 meter / White low loss

Mechanical data

• Materials: Galvanized steel, thermoplastic UV stabilized, PCB
• Mast Ø: 25 - 42 mm
• Max wind resistance: 200 km/h
• Length: 166 mm
• Height: 355 mm
• Width: 144 mm
• Weight: 350 gram
• Mounting type: On mast, on wall

Inside the box

• Antenna: Yes
• Radio connector: SMA-male
• Mounting parts: Yes
• Antenna cable: Yes
• Installation manual: English

Downloads

• Datasheet: Id 426 11 05 2016 HGO 4 G LTE
