Sirio - ML 145 MAG

Product code: 2000145

Factory code: 2201805.63

Barcode: 8056182110343

One of the most popular CB and 10 meter band magnet antennas with a very good performance. Stainless steel whip with a stainless steel spring for the best flexibility. All metallic parts are of chromed brass to get the best robustness.

Frequency range: 27 - 28.5 MHz

Out of stock - Longer delivery time

€52.95 (43.76 excl. 21% VAT)

Electrical data

• Electrical type: Base loaded
• VSWR: ≤ 1.2
• Bandwidth: 1340 kHz ≤ 2.0
• Maximum continuous power: 300 Watts (CW)
• Power peak: 900 Watts (CW)
• Impedance: 50 Ohm
• Polarization: Linear vertical
• Cable: Yes
• Cable length: 3.6 meter / RG 58

Mechanical data

• Materials: Copper, brass, stainless steel 17/7 PH, nylon
• Height: 1420 mm
• Weight: 1250 gram
• Mounting type: 127 mm magnet

Inside the box

• Antenna: Yes
• Radio connector: UHF-male (PL)
• Mounting parts: Yes
• Antenna cable: Yes
• Installation manual: English, Italian

Downloads

• Datasheet: Id 032 10 03 2008 ml145
