Sirio - SCO-2.4-6 Mariner / SMA-m

Product code: 233152083

Factory code: 2331520.83

Marine antenna working on 2.3-2.5 GHz conceived for WLAN system. The radiant element is made of PTFE PCB to guarantee high power and low losses and it is protected by a glassfibre tube. SCO-2.4-6 MARINER is supplied with RG 58 cable directly connected and SMA-male. Including the “M8” adjustable mount of white nylon.

Frequency range: 2.3 - 2.5 GHz

Out of stock - Longer delivery time

€64.95 (53.68 excl. 21% VAT)

Electrical data

• Electrical type: Colinear Dipole Array
• Gain: 6 dBi
• VSWR: ≤ 1.5
• Maximum continuous power: 20 Watts (CW)
• Impedance: 50 Ohm
• Polarization: Linear vertical
• Cable: Yes
• Cable length: 5.5 meter / White RG 58

Mechanical data

• Materials: Aluminium, stainless steel, chromed Brass
• Height: 340 mm (without mount)
• Weight: 470 gram
• Mounting type: Desk mount

Inside the box

• Antenna: Yes
• Radio connector: SMA-male
• Mounting parts: Yes
• Antenna cable: Yes
• Installation manual: English

Downloads

• Datasheet: SMA M M 8 NY W LAN
