Sirio - SD 1300 N

Product code: 209103
Factory code: 2105505.00
Barcode: 8056182112293

Wide-band discone antenna working on 25 - 1300 MHz in reception and on many amateur frequencies in transmission (6m, 2m, 70cm, 33cm and 23cm band). It is made of stainless steel, chromed brass and anodized aluminium to guarantee the best efficiency and performance. Easy to fit, it can be suitable for the installation everywhere. The vertical whip can be removed whenever the 50 MHz frequency is not required.

Frequency range: TX: 49.5 - 50.5 / 120 - 180 / 215 - 300 / 415 - 465 / 610 - 650 / 710 - 1000 / 1130 - 1300 MHz, RX: 25 - 1300 MHz
Shipped next business day
€119.95 (99.13 excl. 21% VAT)

Electrical data

  • Electrical type: Discone
  • Gain: 0 dBd, 2.15 dBi
  • VSWR: See the product manual under downloads
  • Maximum continuous power: VHF: 300 Watts / UHF: 200 Watts
  • Impedance: 50 Ohm
  • Polarization: Linear vertical

Mechanical data

  • Materials: Aluminium, chromed brass, stainless steel, nylon
  • Mast Ø: 25 - 54 mm
  • Max wind resistance: 130 km/h
  • Height: 1600 mm
  • Weight: 1140 gram
  • Mounting type: On mast
  • Antenna connector: N-female

Inside the box

  • Antenna: Yes
  • Mounting parts: Yes
  • Installation manual: English
