Sirio - SKA 900 1/4 MAG

Product code: 220713075

Factory code: 2207130.75

Vehicular antennas working on AMPS, TACS or E-GSM 900 cellular systems. They are supplied with CELL-MAG, the Micro Magnetic Mount which is suitable to be used with 4 different whips (see drawings) thanks to its universal threaded connection. In spite of its very reduced dimensions, CELL-MAG can bear a traction power of 15 Kg and it is supplied with 3 meter cable RG 58 C/U and FME-female connector.

Frequency range: 824 - 960 MHz

Shipped next business day - Stock: 3

€19.95 (16.49 excl. 21% VAT)

Electrical data

• Electrical type: 1/4 λ
• Gain: 0 dB
• VSWR: ≤ 1.8
• Maximum continuous power: 30 Watts (CW)
• Impedance: 50 Ohm
• Polarization: Linear vertical
• Cable: Yes
• Cable length: 3 meter / RG 58

Mechanical data

• Materials: Chromed brass, stainless steel 17/7 PH, nylon, siliconic rubber
• Height: 68 mm
• Weight: 250 gram
• Mounting type: 41 mm magnet
• Antenna connector: FME female (on cable end)

Inside the box

• Antenna: Yes
• Radio connector: FME-female
• Mounting parts: Yes
• Antenna cable: Yes
• Installation manual: English

Downloads

• Datasheet: Id 281 15 10 2003 MICROMAG LTE
