Sirio - SLP 4G-LTE Cable

Product code: 211200100

Factory code: 2112001.00

Barcode: 8056182112309

New - Directional wide band log periodic antenna from 698 to 2700 MHz, no tuning required! Compact dimensions, high lineair gain, good SWR response. Made of aluminium and high quality materials, low weight. Vertical and horizontal polarization.

Frequency range: 698 - 2700 MHz

Shipped next business day - Stock: 2

€109.95 (90.87 excl. 21% VAT)

Electrical data

• Electrical type: Log periodic
• Gain: 9 - 11 dBi
• VSWR: ≤ 1.2 - 1.8, see the product manual under downloads
• Maximum continuous power: 10 Watts (CW)
• Impedance: 50 Ohm
• Polarization: Linear vertical / Linear horizontal /
• Cable length: 50 cm / White low loss

Mechanical data

• Materials: Aluminium, galvanized steel, thermoplastic UV stabilized
• Mast Ø: 25 - 42 mm
• Max wind resistance: 130 km/h
• Length: 850 mm
• Height: 290 mm
• Width: 50 mm
• Weight: 830 mm
• Mounting type: On mast
• Tuning radius: 820 mm

Inside the box

• Antenna: Yes
• Radio connector: SMA-male
• Mounting parts: Yes
• Antenna cable: Yes
• Installation manual: English

Downloads

• Datasheet: Id 461 29 08 2019 slp 4g lte
