Sirio - SMP 4G LTE Cable

Product code: 211100300

Factory code: 2111003.00

Barcode: 8056182115584

Very compact directional multi-band panel antenna for 790 - 960 MHz, 1.71 - 2.7 GHz for 4G LTE, W-LAN 2.4 and other bands, no tuning required.

Easy and quick installation on mast or wall.

Frequency range: 790 - 960 MHz / 1.71 - 2.7 GHz

Shipped next business day - Stock: 1

€74.95 (61.94 excl. 21% VAT)

Electrical data

• Electrical type: Mini panel
• Gain: 790 - 960 MHz: 6-7 dBi / 1.71 - 1.88 GHz: 9 dBi / 1.92 - 2.17 GHz: 9 dBi / 2.3 - 2.7 GHz: 8-9 dBi
• VSWR: See the product manual under downloads
• Maximum continuous power: 790 - 960 MHz: 30 Watts (CW) / 1.71 - 1.88 GHz: 15 Watts (CW) / 1.92 - 2.17 GHz: 10 Watts (CW) / 2.3 - 2.7 GHz: 10 Watts (CW)
• Impedance: 50 Ohm
• Polarization: Linear vertical
• Cable: Yes
• Cable length: 30 cm / White low loss

Mechanical data

• Materials: Galvanized steel, thermoplastic UV stabilized, PCB
• Mast Ø: 25 - 42 mm
• Max wind resistance: 180 km/h
• Length: 154 mm
• Height: 134 mm (170 mm including mounting base)
• Width: 46 mm (66 mm including mounting base)
• Weight: 400 gram
• Mounting type: On mast, on wall

Inside the box

• Antenna: Yes
• Radio connector: SMA-male
• Mounting parts: Yes
• Antenna cable: Yes
• Installation manual: English

Downloads

• Datasheet: Id 445 16 06 2016 smp 4g lte
