Sirio - SMP 4G LTE MiMo Cable

Product code: 211140300

Factory code: 2111403.00

Barcode: 8056182113573

Upgraded - Very compact directional multi-band panel antenna for 790 - 960 MHz, 1.71 - 2.7 GHz for 4G LTE MiMo systems, no tuning required. 2x wide band elements in single case.

Easy and quick installation on mast or wall. Suitable for indoor and outdoor use.

Frequency range: 790 - 960 MHz / 1.71 - 2.7 GHz

Shipped next business day

€84.95 (70.21 excl. 21% VAT)

Electrical data

• Electrical type: Mini panel
• Gain: 790 - 960 MHz: 5 dBi / 1.71 - 2.7 GHz: 8 dBi
• VSWR: See the product manual under downloads
• Maximum continuous power: 790 - 960 MHz: 20 Watts (CW) / 1.71 - 2.7 GHz: 8 Watts (CW)
• Impedance: 50 Ohm
• Polarization: Linear vertical
• Cable: Yes
• Cable length: 2x 30 cm / White low loss

Mechanical data

• Materials: Galvanized steel, thermoplastic UV stabilized, PCB
• Mast Ø: 25 - 42 mm
• Max wind resistance: 180 km/h
• Length: 154 mm
• Height: 134 mm (170 mm including mounting base)
• Width: 46 mm (66 mm including mounting base)
• Weight: 400 gram
• Mounting type: On mast, on wall

Inside the box

• Antenna: Yes
• Radio connector: 2x SMA-male
• Mounting parts: Yes
• Antenna cable: Yes
• Installation manual: English

Downloads

• Datasheet: Id 421 04 09 2019 smp 4g mimo
