Sirio - SMP 5G LTE Cable

Product code: 211220300

Factory code: 2112203.00

Barcode: 8056182115874

Very compact directional multi-band panel antenna for 698 - 960 MHz, 1.71 - 3.8 GHz for 5G, 4G LTE, W-LAN 2.4 and other bands, no tuning required. The antenna is equipped with 30 centimeter white low loss cable and SMA male connector.

Easy and quick installation on mast or wall.

Frequency range: 698 - 960 MHz / 1.71 - 3.8 GHz

Shipped next business day

€83.95 (69.38 excl. 21% VAT)

Electrical data

• Electrical type: Mini panel
• Gain: 698 - 960 MHz: 4-6 dBi / 1.71 - 2.17 GHz: 9-10 dBi / 2.3-2.7 GHz: 11-12 dBi / 3.3-3.8 GHz: 11-12 dBi
• VSWR: See the product manual under downloads
• Maximum continuous power: 698 - 960 MHz: 35 Watts (CW) / 1.71 - 2.17 GHz: 35 Watts (CW) / 2.3 - 2.7 GHz: 25 Watts (CW) / 3.3 - 3.8 GHz: 20 Watts (CW)
• Impedance: 50 Ohm
• Polarization: Linear vertical
• Cable: Yes
• Cable length: 30 cm / White low loss

Mechanical data

• Materials: Galvanized steel, Thermoplastic UV stabilized, PCB
• Mast Ø: 25 - 42 mm
• Max wind resistance: 180 km/h
• Length: 154 mm
• Height: 134 mm (170 mm including mounting base)
• Width: 46 mm (66 mm including mounting base)
• Weight: 400 gram
• Mounting type: On mast, on wall

Inside the box

• Antenna: Yes
• Radio connector: SMA-male
• Mounting parts: Yes
• Antenna cable: Yes
• Installation manual: English

Downloads

• Datasheet: Id 479 04 05 2021 SMP 5 G
