Sirio - SMP 5G LTE Cable 5M

Product code: 21122035

Factory code: 2112203/5SMA

Barcode: 8056182115881

Very compact directional multi-band panel antenna for 698 - 960 MHz, 1.71 - 3.8 GHz for 5G, 4G LTE, W-LAN 2.4 and other bands, no tuning required. The antenna is equipped with 5 meter white low loss cable and SMA male connector.

Easy and quick installation on mast or wall.

Frequency range: 698 - 960 MHz / 1.71 - 3.8 GHz

Out of stock - Longer delivery time

€86.95 (71.86 excl. 21% VAT)

Electrical data

• Electrical type: Mini panel
• Gain: 698 - 960 MHz: 4-6 dBi / 1.71 - 2.17 GHz: 9-10 dBi / 2.3-2.7 GHz: 11-12 dBi / 3.3-3.8 GHz: 11-12 dBi
• VSWR: See the product manual under downloads
• Maximum continuous power: 698 - 960 MHz: 35 Watts (CW) / 1.71 - 2.17 GHz: 35 Watts (CW) / 2.3 - 2.7 GHz: 25 Watts (CW) / 3.3 - 3.8 GHz: 20 Watts (CW)
• Impedance: 50 Ohm
• Polarization: Linear vertical
• Cable: Yes
• Cable length: 5 meter / White low loss

Mechanical data

• Materials: Galvanized steel, Thermoplastic UV stabilized, PCB
• Mast Ø: 25 - 42 mm
• Max wind resistance: 180 km/h
• Length: 154 mm
• Height: 134 mm (170 mm including mounting base)
• Width: 46 mm (66 mm including mounting base)
• Weight: 400 gram
• Mounting type: On mast, on wall

Inside the box

• Antenna: Yes
• Radio connector: SMA-male
• Mounting parts: Yes
• Antenna cable: Yes
• Installation manual: English

Downloads

• Datasheet: Id 479 04 05 2021 SMP 5 G
