Sirio - SMP-918-9 Cable

Product code: 21100300

Factory code: 2111003.00

Directional multi-band base station antenna for indoor or outdoor use working on 880 - 960 MHz and 1.7 - 2.17 GHz conceived for GSM 900 & 1800, PCS 1.9 GHz, DECT and UMTS systems. The radiant element is made on a PCB and it is protected by a thermoplastic UV-stabilized radome to get the best performance for long periods of time. It’s supplied with bracket for an easy installation on the mast. With 30 cm low loss cable with SMA-male connector.

Frequency range: 880 - 960 MHz / 1.71 - 2.17 GHz

Out of stock - Longer delivery time

€49.95 (41.28 excl. 21% VAT)

Electrical data

• Electrical type: Mini panel
• Gain: 9 dBi
• VSWR: See the product manual under downloads
• Maximum continuous power: 20 Watts (CW)
• Impedance: 50 Ohm
• Polarization: Linear vertical
• Cable: Yes
• Cable length: 30 cm / White low loss

Mechanical data

• Materials: Galvanized steel, thermoplastic UV stabilized, PCB
• Mast Ø: 25 - 42 mm
• Max wind resistance: 180 km/h
• Length: 154 mm
• Height: 134 mm (170 mm including mounting base)
• Width: 46 mm (66 mm including mounting base)
• Weight: 400 gram
• Mounting type: On mast, on wall

Inside the box

• Antenna: Yes
• Radio connector: SMA-male
• Mounting parts: Yes
• Antenna cable: Yes
• Installation manual: English

Downloads

• Datasheet: Id 318 09 03 2009
