Sirio - SO 4G LTE Cable

Product code: 211152080

Factory code: 2111520.80

Barcode: 8056182113597

New - Multi-band base station antennas conceived for LTE 790, ISM 868 MHz, GSM 900 & 1800, DSC 1.9, UMTS, W-LAN 2.4 and LTE 2.5 systems working on 790 - 960 MHz and 1710 - 2700 MHz. The radiant dipole is made of brass and protected by a fiberglass tube. With 5 meter low loss cable and SMA-male connector. Including the Sirio M3 bracket for wall or mast mount.

Frequency range: 790 - 960 MHz / 1.71 - 2.4 GHz

Out of stock - Longer delivery time

€69.95 (57.81 excl. 21% VAT)

Electrical data

• Electrical type: Colinear dipole array
• Gain: 790-960 MHz: 2 dBi / 1.71-2.7 GHz: 4 dBi
• VSWR: ≤ 2.2, see the product manual under downloads
• Maximum continuous power: 25 Watts (CW)
• Impedance: 50 Ohm
• Polarization: Linear vertical
• Cable: Yes
• Cable length: 5 meter / White low loss

Mechanical data

• Materials: Aluminium, anodized aluminium, nickel plated brass, stainless steel, galvanized steel
• Mast Ø: 35 - 42 mm
• Max wind resistance: 200 km/h
• Height: 300 mm
• Weight: 495 gram
• Mounting type: On mast, on wall

Inside the box

• Antenna: Yes
• Radio connector: SMA-male
• Mounting parts: Yes
• Antenna cable: Yes
• Installation manual: English

Downloads

• Datasheet: Id 454 16 05 2018 so 4g lte
