Sirio - SPO 118-2

Product code: 2115020118

Factory code: 2115020/118

Wide band omnidirectional base station antenna suitable for VHF AIR band. The fiberglass protection radome and the anodized aluminium parts guarantee robustness and long life to all the SPO-antennas series. They are supplied with two strong extruded aluminium brackets and stainless steel hardware for a good installation on the mast.

Frequency range: RX: 108-136 MHz, TX 118-136 MHz

Shipped next business day - Stock: 2

€159.95 (132.19 excl. 21% VAT)

Electrical data

• Electrical type: Dipole
• Gain: 0 dBd - 2.15 dBi
• VSWR: ≤ 1.5
• Maximum continuous power: 100 Watts (CW)
• Impedance: 50 Ohm
• Polarization: Linear vertical
• Radiation (H-plane): 360° Omnidirectional
• Radiation (E-plane): Beamwidth @ -3dB = 78°
• Radiation angle deg.: 0°

Mechanical data

• Materials: Anodized aluminium, brass, stainless steel, fiberglass, EPDM rubber, copper
• Mast Ø: 35 - 54 mm
• Max wind resistance: 180 km/h
• Height: 1700 mm
• Weight: 1400 gram
• Mounting type: On mast
• Antenna connector: N-female
• Operating temperature: -40°C to + 80°C
• Wind Load at 150 km/h: 56 N
• Wind Surface: 0.048 m²

Inside the box

• Antenna: Yes
• Mounting parts: Yes
• Installation manual: English

Downloads

• Datasheet: Datasheet SPO 118 2
