Sirio - T3 27 MAG

Product code: 220701561

Factory code: 2207015.61

Barcode: 8056182114433

The popular T3-27 antenna on a strong magnet. Tunable top screw to fine-tune the antenna, with a protective rubber cap. Can be used for a temporary installation and as back-up antenna.

Frequency range: 26.9 - 27.5 MHz

Out of stock - Longer delivery time

€46.95 (38.8 excl. 21% VAT)

Electrical data

• Electrical type: Logarithmic loaded
• VSWR: ≤ 1.2
• Bandwidth: 700 kHz (65 channels) ≤ 2.0
• Maximum continuous power: 20 Watts (CW)
• Power peak: 100 Watts (CW)
• Impedance: 50 Ohm
• Polarization: Linear vertical
• Cable: Yes
• Cable length: 4 meter / RG 58

Mechanical data

• Materials: Brass, stainless steel, nylon
• Height: 620 mm
• Weight: 400 gram
• Mounting type: 92 mm magnet
• Antenna connector: UHF (PL) male

Inside the box

• Antenna: Yes
• Radio connector: UHF-male (PL)
• Mounting parts: Yes
• Antenna cable: Yes
• Installation manual: English, Italian

Downloads

• Datasheet: Id 152 02 07 2008 t series
