TTI - TCB-560evo TTI - TCB-560evo TTI - TCB-560evo TTI - TCB-560evo TTI - TCB-560evo TTI - TCB-560evo

TTI - TCB-560evo

Product code: 50560
Factory code: 801-C560-E00
Barcode: 8809075220045

The new and compact TTI TCB-560evo comes with a VOX function, noise blanker and 7 display colors. It is the successor of the popular TTI TCB-560. It also features Dynamic Squelch (DSS), scan function and 12/24 Volt dual voltage.

New features and functions on the TTI TCB-560evo are:

  • 7 display colors
  • VOX function, can be (de)activated directly from the radio
  • Noise blanker
Frequency range: 26.965 - 27.405 MHz
Shipped next business day
€74.95 (61.94 excl. 21% VAT)

Features

  • Modulation: AM / FM
  • Multi-bands: Yes
  • Output power: 4 Watt / Duty cycle 10% @ 13.2V DC
  • Channels: 40 AM / FM
  • Display type: LCD display
  • Display colors: Green / Orange / Purple / Dark Blue / Light Blue / Yellow / Clear Blue
  • VOX Function: Yes
  • Noise blanker: Yes
  • Squelch: DSS (Dynamic Squelch System) / Manual squelch /
  • Emergency channel: Yes
  • Scan function: Yes
  • External speaker socket: Yes

Electrical data

  • Voltage: 13,8 Volt / 24 Volt /
  • Operating temperature: -10° to +55° C
  • Operating mode: F3E (FM) / A3E (AM)
  • Frequency control: PLL synthesizer
  • Frequency tolerance: 0.002 %

Transmitter

  • Audio frequency response: 300 Hz - 3 kHz
  • Modulation AM: From 85% to 95%
  • Modulation FM: 1.8 kHz to ± 0.2 kHz
  • Harmonic suppression: More than -36 dBm
  • Drain: 13.2 Volt: 1.6 A max.

Receiver

  • AM sensitivity: 0.7 µV for 10 dB
  • FM sensitivity: 0.5 µV for 20 dB SINAD
  • Frequency response: 300 Hz - 2.5 kHz
  • Adjacent channel selectivity: 60 dB
  • Maximum audio power: 2 Watt
  • Internal speaker: 8 Ohm, round
  • Receiving system: Dual conversion superheterodyne
  • IF frequencies: Double conversion 1st 10.695 MHz / 2nd 455 kHz
  • Audio distortion: Less than 8% @ 1 kHz
  • Image rejection: 60 dB
  • Conducted spurious: More than 60 dB
  • Squelch: Adjustable, threshold less than 1 µV,

Mechanical data

  • Length: 135 mm
  • Height: 37 mm
  • Width: 124 mm
  • Weight: 655 gram
  • Antenna connector: UHF (PL) female (SO-239)
  • Mike connector: 6 pin connector

Inside the box

  • Transceiver: 1 pcs
  • Microphone: 1 pcs
  • Fixing screws: 1 set
  • Mounting bracket: 1 pcs
  • Power lead: 1 pcs
  • User Manual: English
