Vero - VGC VR-N76 Orange

Product code: 40165
Factory code: 40165

The VGC VR-N76 is an innovative VHF and UHF handheld radio that sets new standards with a variety of modern features.

With a 5-watt transmission power, convenient app control, built-in Bluetooth, GPS, GPRS, compass, and much more, the VR-N76 redefines what an analogue handheld radio can do.

Enjoy exciting and useful features that were previously only available to digital radio users – but without the hassle of getting to grips with complex digital systems.

Key features:

  • Bluetooth Integration: Experience full Bluetooth functionality, including offline programming and firmware updates – even without a mobile connection.
  • App Connectivity: Use the free HT app to customise every aspect of your radio and take full control during operation – even remotely.
  • Firmware Upgradeable: Easily update firmware via the free app.
  • GPS and Compass: Navigate safely with built-in GPS and compass – perfect for outdoor adventures and accurate location tracking.
  • Waterproof to IP67: Fully waterproof design offers robust protection against environmental elements – ideal for water sports or heavy rain during hikes.
  • Powerful 2-Watt Speaker: Delivers clear audio, even in noisy environments.
  • FM Radio and AM Airband Reception: Wideband receiver also covers FM broadcast (88 to 108 MHz) and AM airband (108 to 136 MHz).

Key app features:

  • Network Communication: Enables communication over networks.
  • Global Connectivity: Connect with friends worldwide via network links.
  • SSTV Image Reception: Receive SSTV images directly via the app.
  • Morse Code Transmission: Send Morse code using the app.
  • Offline Maps: Download offline maps for location viewing without network coverage.
  • Remote Control: Control local radios remotely via the app – including frequency changes.

Please note that some features only function when used in combination with the app.

For complete specifications and features, refer to the user manual available in the "Downloads" section at the bottom of this product page.

Frequency range: TX/RX: 136-174 / 400-470 MHz
Shipped next business day - Stock: 8
€144.95 (119.79 excl. 21% VAT)

Features

  • Display: Yes, large LCD display
  • High/low power selection: Yes
  • Battery capacity: Li-Ion 2600 mAh (7,2 V)
  • Accessory connector: 2-pin Motorola connector (M1)
  • USB C connector: Yes, can be used for charging
  • Standby Time: Approx. 48 hours
  • CTCSS and DCS tone codes: Yes
  • Position & Direction Display: Yes
  • Real-Time Track Logging: Yes
  • Live Positioning: Yes
  • Team Trajectory Tracking: Yes
  • APRS / BSS: Yes
  • Mobile Phone App: Yes
  • Manual Frequency Input: Yes
  • GPS + BeiDou support: Yes

Electrical data

  • Frequency step: 12.5 kHz / 25 kHz /
  • Operating temperature: -20℃ to +60℃
  • Frequency stability: ±2.5 PPM

Transmitter

  • Power output (Watts): ≤5W
  • Audio distortion: ≤5%
  • Adjacent channel power suppression: ≤-68dB
  • Clutter and Harmonics: ≤-60dB
  • FM noise: 45 dB
  • FM distortion: ≤3%

Receiver

  • Sensitivity: 0.16uV
  • Adjacent channel selectivity: ≥68dB
  • Intermodulation Immunity: ≥65dB
  • Spurious Response Immunity: ≥65dB
  • Audio distortion: ≤3%
  • Audio output power: 2W

Mechanical data

  • Length: 60 mm
  • Height: 115 mm
  • Width: 40 mm
  • Weight: 312 gram
  • Antenna connector: SMA male

Inside the box

  • Transceiver: Yes
  • Battery: Li-Ion 2600 mAh
  • Antenna: Yes
  • Installation manual: English
  • Belt clip: Yes
  • USB-C: Yes
