Wouxun - KG-D26 Wouxun - KG-D26 Wouxun - KG-D26 Wouxun - KG-D26 Wouxun - KG-D26 Wouxun - KG-D26 Wouxun - KG-D26 Wouxun - KG-D26

Wouxun - KG-D26

Product code: 34026
Barcode: 6946351706106

The new Wouxun KG-D26 dPMR is fully compatible, analog and digital, with the Kenwood TK-3401D, TK-3601D and TK-3701D series.

The hidden display is integrated in the strong radio body, which prevents it from damaging. It will clearly show you the: channel number, analogue / digital mode, current zone, high / low power, narrow / wide band width, battery status, signal status, VOX indicator, DCS/CTCSS indicator and time slot 1 / 2 indicator.

With the battery save on mode the 2000 mAh battery pack can last up to 30 hours (5% transmit, 5% receive, 90% standby).

Frequency range: 446.0 - 446.2 MHz
Out of stock - Longer delivery time
€179.95 (148.72 excl. 21% VAT)

Features

  • Number of channels: 16
  • Number of zones: 99 programmable (3 zones preprogrammed)
  • Output power: 0.5 Watt (6 Watt export only)
  • Channel spacing analogue: 12.5 kHz
  • Channel spacing digital: 6.25 kHz
  • Battery saver mode: Yes
  • Call alert: Yes
  • Programmable function keys: Yes
  • PC programming: Yes
  • Display: Yes
  • Display colors: Green
  • High/low power: Yes
  • Battery capacity: Li-ion 2000 mAh
  • Accessory connector: 2-pin Kenwood connector (K)
  • Voice guide: English and Chinese
  • VOX function: Yes, activation by software
  • Scan function: Yes, activation by software
  • Flashlight: Yes
  • RX group list: 32 groups, 8 members per group
  • Scanning list: 16 groups, 16 channels per group
  • IP code: IP55

Electrical data

  • Channels: 10000
  • Frequency stability: ± 1.0 ppm
  • RX sensitivity: 0.25 uV
  • Microphone modulation: 120 mV
  • Microphone distortion: 12 mV
  • Adjacent channel power: > 60 dB at narrow bandwidth
  • Error radio: -118 dBm
  • Offset frequency: 100 Hz
  • Modulation: +3dB –3dB
  • Spurious Emission: > -57 d
  • Audio: +2 dB -10 dB
  • Audio output: Internal speaker 1 W - 12 Ohm / external output 1 W - 16 Ohm

Mechanical data

  • Length: 53 mm
  • Height: 245 mm
  • Width: 33 mm
  • Weight: 245 gram
  • Antenna connector: SMA male
  • Operating voltage: 7.5V DC ± 20%
  • Battery life: Battery save off: 24 hours, battery save on: 30 hours (5% transmit, 5% receive, 90% standby)

Inside the box

  • Radio: 1 pcs
  • Desktop charger: 1 pcs
  • Wall adapter: 1 pcs
  • Batteries (pack): 1 pcs
  • Belt clip: 1 pcs
  • User manual: English
