Zetagi - MM 27

Product code: 925004

The Zetagi MM 27 is an antenna matcher / tuner with a frequency range from 26 - 28 MHz. The MM 27 can be used with a maximum power of 100W AM.

Frequency range: 26 - 28 MHz

Note - Discontinued

€ -- (Discontinued)

Electrical data

• Impedance: 50 Ohm
• Power range: 100W AM
• Insertion loss: 0.2 db

Mechanical data

• Input connector: UHF (PL) female
• Output connector: UHF (PL) female
• Length: 45 mm
• Height: 43 mm
• Width: 105 mm
• Weight: 200 gram

Inside the box

• Matcher: Yes
• Installation manual: English
